μClamp®series are designed to protect sensitive electronics from damage or latch-up due to ESD. They feature large cross-sectional area junctions for conducting high transient currents. They offer desirable characteristics for board level protection including fast response time, low operating and clamping voltage, and no device degradation.
- High ESD withstand Voltage: ±30kV (contact) and ±30kV (air) per IEC 61000-4-2
- High peak pulse current capability: 80A (tp = 8/20μs)
- Ultra small package (1.0 x 0.6 x 0.25mm)
- Protects one I/O or power line
- Low ESD clamping voltage
- Working voltage: ± 3.3V
- Cellular Handsets & Accessories
- Battery Protection
- Notebooks & Handhelds
- USB Voltage Bus
- Audio Lines
- DFN 1.0x0.60x0.25mm-2 Lead
