The RailClamp®3331PQ is a low voltage, low-capacitance, automotive-grade RailClamp transient voltage suppressor (TVS) optimized for safeguarding antennas and high-speed data ports from electrostatic discharge (ESD) threats. The low-capacitance of the RClamp3331PQ makes it an ideal protection device for safeguarding automotive-based antennas from ESD transients.
- High ESD withstand Voltage: ±30kV (Air and Contact) per IEC 61000-4-2
- Ultra-small package
- Protects one line
- Low ESD clamping voltage
- Working voltage: ±3.3V
- Low capacitance: 0.35 pF Typical
- Low leakage current
- Low dynamic resistance
- Qualified to AEC-Q100, Grade 1
- Solid-state silicon-avalanche technology
- USB3.0 / USB 3.1/ USB Type-C
- Automotive Applications
- Industrial Equipment
